Greenlee High Voltage Ammeter 2000A HVA-2000
Original price was: $1,986.00.$138.99Current price is: $138.99.
Additional Details
Greenlee
High Voltage Ammeter 2000A HVA-2000
FEATURES:
- Measures AC current from 1 to 2000 Amps on system voltages up to 500kV line-to-ground
- Stores the last 4 readings
- Dual measurement modes; peak hold and real time
- Takes spot-load checks with ease
- Verifies phases are balanced
- Versatile for overhead and underground applications
- Compact; lightweight design
SPECIFICATIONS:
| Sub Brand | HDE |
|---|---|
| Type | Ammeter |
| Model | HVA-2000 |
| Voltage Rating | 0 – 500kV line-to-ground |
| Amperage Rating | 1 -2000A |
| Accuracy | 50-60Hz – 1–10A – 1% +/-2 counts; 11–100A – 1% +/-3 counts; 101–500A – 1% +/-6 counts; 501–2000A – 1% +/-8. 252-49Hz and 61-500Hz – 1–10A – 2% +/-3 counts; 11–100A – 2% +/-4 counts; 101–500A – 2% +/-6 counts; 501–2000A – 2% +/-8 counts |
| Display | LED display |
| Operating Temperature | -20°F to +140°F (-29°C to +60°C) |
| Dimensions | 4”H x 6.6”W x 11.5”L |
| Frequency Rating | 25 – 500Hz |
| Included | HVA-2000 Ammeter; B-5 Bag |
Manufacturer Specifications
| Type | Ammeter |
|---|---|
| Sub Brand | HDE |
| Country of Origin | United States |
| Dimensions | 4â€H x 6.6â€W x 11.5â€L |
| Amperage Rating | 1 -2000A |
| Model | HVA-2000 |
| Accuracy | 50-60Hz – 1–10A – 1% +/-2 counts, 11–100A – 1% +/-3 counts, 101–500A – 1% +/-6 counts, 501–2000A – 1% +/-8. 252-49Hz and 61-500Hz – 1–10A – 2% +/-3 counts, 11–100A – 2% +/-4 counts, 101–500A – 2% +/-6 counts, 501–2000A – 2% +/-8 counts |
| Included | HVA-2000 Ammeter, B-5 Bag |
| Operating Temperature | -20°F to +140°F (-29°C to +60°C) |
| Display | LED display |
| Voltage Rating | 0 – 500kV line-to-ground |
| Frequency Rating | 25 – 500Hz |
Specifications
| OPT SKU | GRHVA-2000 |
|---|---|
| MPN | HVA-2000 |
| UPC/GTIN | 783310628309 |
| Product Type | Voltage Testing & Measuring |
| Google Category | Hardware > Tools > Measuring Tools & Sensors > Electrical Testing Tools |
| Power Method | Cordless |
| Shipping Weight | 8.00 |
